Rapid auto roll doors, also known as high speed roll doors are a type of doors commonly used in a variety of industrial workspaces, where rapid opening and closing of tall barriers are required, seeing use in industries such as electronics, precision machinery, logistics, food, auto repairs, just to name a few.

DMF rapid auto roll doors feature inherent thermal insulation, anti-dust, anti-wind and anti-odour nature, which can be customized based on requirements of specific industries and workplaces. They are indispensable in helping to save energy and improve workflow through providing better environment for various operations.

website service
website service
website service

Technical Facts:- RL3000B

Features (* Other sizes may available on request)

  • Max Size: (W x H)*:6000 mm x 6000mm
  • Fabric Thickness: 2 mm thick
  • Fabric Type/Panel: Duracover panel with full width clear section
  • Aluminium Wind Rail: 2 nos.
  • Colour: Blue, Orange, Red or Grey
  • Side Column Material: Standard columns with full brush sealing
  • Roller Tube: Fluted, with heavy brackets
  • Bottom Bar: Composite Aluminium / Flexible
  • Windows: Optional: window / clear section
  • Control/Operation: Interlocking / Integration with equipment / Security access

  • Performance

  • Operating Speed: 1.0m/s   Closing: 0.6 m/s
  • Wind Load Resistance, EN12424: 450N/m²
  • Lifetime Expectations: 4,000,000 cycles
  • Power Supply Requires: 415V 3 Phase 15A
  • Motor Size: 0.37kW – 0.75kW 2 speed
  • Auto Close with variable hold open timer:Yes
  • In-line Safety PE Sensor:Yes
  • Specification :

  • For Intense Traffic Flow
  • Safe & Reliable Operation (CE-MARKED)
  • Energy Saving
  • Improved Working Environment
